Life:
100000 (Electrical) operations, 20000000 (Mechanical) operations
Depth:
21.5mm
Height:
36mm
Length:
28mm
Latching:
No
Coil Power:
1.8W
Application:
General Purpose
Coil Voltage:
24V ac
Mounting Type:
Chassis Mount
Standards Met:
CQC, cUL, CULus, IECQ QC 080000 Certified, OHSAS 18001, TUV, UL, VDE
Terminal Type:
Plug In
Coil Resistance:
184Ω
Number of Poles:
4
Contact Material:
Silver Alloy
Switching Current:
5A
Contact Configuration:
4PDT
Isolation Coil To Contact:
1.5kV
Maximum Switching Power AC:
1.25 kVA
Maximum Switching Power DC:
150 W
Maximum Switching Voltage AC:
250V
Maximum Switching Voltage DC:
30V dc
Maximum Operating Temperature:
+70°C
Minimum Operating Temperature:
-40°C
Maximum Switching Voltage DC:
30V
Standards Met:
CQC, cUL, CULus, IECQ QC 080000 Certified, OHSAS 18001, TUV, UL, VDE
Mounting Type:
Chassis Mount
Coil Power:
1.8W
Latching:
No
Coil Voltage:
24V ac
Length:
28mm
Height:
36mm
Switching Current:
5A
Application:
General Purpose
Depth:
21.5mm
Maximum Switching Voltage AC:
250V
Maximum Switching Power DC:
150 W
Maximum Switching Power AC:
1.25 kVA
Isolation Coil To Contact:
1.5kV
Contact Configuration:
4PDT
Number of Poles:
4
Terminal Type:
Plug In
Coil Resistance:
184Ω
