Digital/Analogue:
Digital
Maximum Temperature:
+40°C
Output Current:
3.2A
Number of Outputs:
3
Series:
T3PS
Input Connector:
IEC 320-C14
Bench Power Supply Type:
Programmable DC Power Supply
Model Number:
T3PS3000
Output Voltage:
0 → 30V
Minimum Temperature:
0°C
Number of Displays:
2
Power Rating:
220W
Type:
Programmable Linear Power Supply
HTSUS:
8504.40.9530
RoHS Status:
RoHS Compliant
Power (Watts):
220W
Moisture Sensitivity Level (MSL):
Not Applicable
Type:
Bench (AC to DC)
Current Regulation - Line:
0.2% + 3mA
Voltage Regulation - Line:
0.01% + 3mV
Current - Output:
0 ~ 3.2A
Accuracy - Voltmeter; Ammeter:
0.03% + 10mV; 0.3% + 10mA
Package:
Box
Size / Dimension:
10.945" L x 8.858" W x 5.630" H (278.00mm x 225.00mm x 143.00mm)
Ripple:
1mV rms
Number of Characters:
4, 5
Current Regulation - Load:
0.2% + 3mA
standardLeadTime:
18 Weeks
Voltage Regulation - Load:
0.01% + 3mV
Display Type:
LCD
Features:
LAN, Programmable, USB Interface
Series:
-
Voltage - Output:
0 ~ 32VDC, 0 ~ 32VDC, 5VDC
Voltage - Supply:
-
Number of Outputs:
3
ECCN:
EAR99
