Depth:
40mm
Width:
40mm
Length:
118mm
IP Rating:
IP68, IP69K
Shielding:
Unshielded
Body Style:
Block
Mounting Type:
Flush
Standards Met:
CCC, CSA, EN 60497-5-2: 2007, IEC 60947-5-2: 2007, UL
Supply Voltage:
5 → 60 V dc
Connection Type:
Screw Terminal
Detection Range:
20 mm
Output Function:
NO/NC
Housing Material:
Polyamide
Sensor Technology:
Inductive
Switching Current:
200 mA
Maximum DC Voltage:
60V
Switching Frequency:
250 Hz
Maximum Switching Frequency:
250Hz
Reverse Polarity Protection:
Yes
Digital Switching Output Type:
2-Wire
Maximum Operating Temperature:
+85°C
Minimum Operating Temperature:
-25°C
Short Circuit Overload Protection:
Yes
Maximum DC Voltage:
60V
Short Circuit Overload Protection:
Yes
Standards Met:
CCC, CSA, EN 60497-5-2: 2007, IEC 60947-5-2: 2007, UL
Mounting Type:
Flush
IP Rating:
IP68, IP69K
Sensor Technology:
Inductive
Switching Current:
200 mA
Length:
118mm
Maximum Switching Frequency:
250Hz
Housing Material:
Polyamide
Width:
40mm
Depth:
40mm
Reverse Polarity Protection:
Yes
Supply Voltage:
5 → 60 V dc
Minimum Operating Temperature:
-25°C
Body Style:
Block
Maximum Operating Temperature:
+85°C
Terminal Type:
M20 Gland
Detection Range:
20 mm
