Housing Material:
Bronze, PBT, PEI
Supply Voltage:
10 → 30 V dc
Shielding:
Unshielded
Standards Met:
CE, cULus, DIN EN 60947-5-2, EAC, EN 55011, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-6, IEC 61131-9
Output Type:
PNP & NPN
Maximum Switching Frequency:
100Hz
Reverse Polarity Protection:
Yes
Detection Range:
13 mm
Body Style:
Barrel
Maximum Operating Temperature:
+85°C
Terminal Type:
4-Pin M12 Connector
IP Rating:
IP65, IP66, IP67, IP68, IP69K
Switching Current:
10 mA
Length:
65mm
Communication Protocol:
IO-LINK
Maximum DC Voltage:
30V
Thread Size:
M30 x 1.5
Short Circuit Overload Protection:
Yes
Mounting Type:
Flush
Sensor Technology:
Inductive
Minimum Operating Temperature:
-40°C
