Width:
12mm
Length:
65mm
Series:
IME12
IP Rating:
IP67
Shielding:
Unshielded
Body Style:
Threaded Barrel
Thread Size:
M12
Mounting Type:
Non-Flush
Standards Met:
CE Certified, cULus Listed
Supply Voltage:
10 → 30 V dc
Connection Type:
M12
Detection Range:
10 mm
Output Function:
NO
Housing Material:
Brass Nickel Plated
Sensor Technology:
Inductive
Switching Current:
10 mA
Maximum DC Voltage:
30V
Switching Frequency:
400 Hz
Maximum Switching Frequency:
400Hz
Reverse Polarity Protection:
Yes
Digital Switching Output Type:
PNP
Maximum Operating Temperature:
+75°C
Minimum Operating Temperature:
-25°C
Short Circuit Overload Protection:
Yes
Housing Material:
Brass Nickel Plated
Width:
12mm
Supply Voltage:
10 → 30 V dc
Shielding:
Shielded
Standards Met:
CE Certified, cULus Listed
Output Type:
PNP
Maximum Switching Frequency:
400Hz
Reverse Polarity Protection:
Yes
Detection Range:
10 mm
Body Style:
Barrel
Maximum Operating Temperature:
+75°C
Terminal Type:
4-Pin M12 Connector
IP Rating:
IP67
Switching Current:
10 mA
Length:
65mm
Maximum DC Voltage:
30V
Thread Size:
M12 x 1
Short Circuit Overload Protection:
Yes
Mounting Type:
Non-Flush
Sensor Technology:
Inductive
Minimum Operating Temperature:
-25°C
