Modes:
Burst, Double Pulse, Function/Arbitrary, Modulation, Noise, Pattern/PBRS, Pulse, Square, Sweep, Triggered
Width:
213.5 (Rack Mount) mm, 250 (Bench Top Mount) mm
Height:
86.5 (Rack Mount) mm, 97 (Bench Top Mount) mm
Jitter:
<30%
Length:
269 (Rack Mount) mm, 295 (Bench Top Mount) mm
Weight:
3.2kg
Dimensions:
269 x 213.5 x 86.5 (Rack Mount) mm, 295 x 250 x 97 (Bench Top Mount) mm
Connector Type:
USB
Interface Type:
GPIB, LAN, LXI, Remote, USB 2.0, USB Flash Drive
Model Number p:
TGP3121
Input Impedance:
10 kΩ
Rise - Fall Time:
5 ns → 399.999999989 s (Double Pulse), 5 ns → 799.999999989 s (Pulse)
Maximum Frequency:
25 (Double Pulse) MHz, 50 (Pulse) MHz
Minimum Frequency:
1 mHz
Maximum Pulse Delay:
999.99999996 (Double Pulse) s, 999.99999998 (Pulse) s
Maximum Pulse Width:
499.99999999 (Double Pulse) s, 999.99999999 (Pulse) s
Minimum Pulse Delay:
0ns
Minimum Pulse Width:
10ns
Adjustable Output Amplitude:
Yes
Maximum Operating Temperature:
+40°C
Minimum Operating Temperature:
+5°C
