Maximum Temperature:
+55°C
Minimum Temperature:
-5°C
Application:
Commercial, Industrial, Military, Telecom
MTBF:
>400000h
Protection Features:
Over Voltage Protection
Holdup Time:
14ms
Load Regulation:
-5 → +5 (V3 & V4) %, -1 → +1 (V1 & V2) %
Standards Met:
CE, CULus, EN 55022 Level-B, EN 61000-3-3, EN 61000-4-11, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, IEC/EN 60950-1, UL/cUL 60950-1, VDE
Input Frequency Range:
47 → 63Hz
Efficiency:
79 → 81%
Input Voltage:
90 → 264V ac
Number of Outputs:
4
Output Voltage Adjustment Range:
3.1 → 3.5 (V2) V, 4.8 → 5.4 (V1) V
Line Regulation:
-0.5 → +0.5%
Ripple And Noise:
60 (V1) mV Pk-Pk, 90 (V2) mV Pk-Pk, 120 (V3 & V4) mV Pk-Pk
Allowed Circuit Configurations:
Parallel
Special Features:
Active Load Current Share, International Regulatory Approvals, PICMG 2.11 Compliant, Ruggedized Construction, Universal AC input with PFC, 3U Form Factor
Power Signal Conversion Type:
AC-DC
Mounting Type:
Rack Mount
Output Current:
3 (V3) A, 20 (V1) A, 30 (V2) A, 500 (V4) mA
Series:
CPCI-3U
Weight:
800g
Output Voltage:
-12 (V4) V, 3.3 (V2) V, 5 (V1) V, 12 (V3) V
Power Rating:
300W
