Contact Resistance:
150 (Static) mΩ, 200 (Dynamic) mΩ
Dimensions:
19.3 x 6.4 x 5.1mm
Coil Voltage:
5V dc
Coil Resistance:
500Ω
Life:
1000000000 (Electrical) cycles
Standards Met:
RoHS Compliant
Coil Power:
50mW
Maximum Switching Voltage DC:
200V dc
Maximum Switching Power DC:
20 W
Isolation Coil To Contact:
1.5kV dc
Maximum Operating Temperature:
+70°C
Terminal Type:
Through Hole
Maximum Switching Current AC:
1 A
Operating Temperature Range:
-20 → +70°C
Contact Configuration:
SPST
Depth:
6.4mm
Mounting Type:
PCB Mount
Operating Time Including Bounce:
0.5ms
Length:
19.3mm
Height:
5.1mm
Maximum Switching Current DC:
1 A
Maximum Switching Voltage AC:
200V ac
Minimum Operating Temperature:
-20°C
