Life:
10^6 (50W Switching) cycles, 10^9 (Dry Switching) cycles
Depth:
15.8mm
Height:
18.5mm
Length:
60mm
Dimensions:
60 x 15.8 x 18.5mm
Coil Voltage:
5V dc
Mounting Type:
PCB Mount
Terminal Type:
PCB Pin
Coil Resistance:
28Ω
Electrical Life:
10^6 (50W Switching) cycles, 10^9 (Dry Switching) cycles
Number of Poles:
1
Contact Material:
Tungsten
Special Features:
7.5kV or 5kV Isolation, Choice of 10kV, Excellent AC Characteristics, Low Contact Resistance, PCB or Panel mΩunt
Contact Resistance:
250 mΩ
Contact Configuration:
SPST
Isolation Coil To Contact:
17kV
Maximum Switching Power DC:
50 W
Operating Temperature Range:
-20 → +70°C
Maximum Switching Current AC:
2 A
Maximum Switching Current DC:
2 A
Maximum Switching Voltage AC:
3500V
Maximum Switching Voltage DC:
3500V
Maximum Operating Temperature:
+70°C
Minimum Operating Temperature:
-20°C
Relay Switching Classification:
General Purpose Relay
Operating Time Including Bounce:
3ms
