Frequency Range:
617MHz ~ 698MHz, 698MHz ~ 824MHz, 824MHz ~ 960MHz, 1.427GHz ~ 1.518GHz, 1.71GHz ~ 2.2GHz, 2.3GHz ~ 2.69GHz, 2.4GHz ~ 2.5GHz, 3.3GHz ~ 4.2GHz, 5.15GHz ~ 5.85GHz, 5.15GHz ~ 5.925GHz, 5.925GHz ~ 7.125GHz
HTSUS:
8529.10.4040
RoHS Status:
ROHS3 Compliant
Frequency Group:
Wide Band
Height (Max):
2.079" (52.80mm)
Applications:
4G, 5G, Beidou, Galileo, GLONASS, GPS, LTE, Wi-Fi
Gain:
1.6dBi, 2.3dBi, 5dBi, 3.4dBi, 1dBi, 1dBi, 1dBi, 6.6dBi, 5.9dBi, 4.2dBi, 5.4dBi, 7.4dBi, 3dBi, 3.6dBi
Number of Bands:
14
Package:
Bulk
Moisture Sensitivity Level (MSL):
1 (Unlimited)
RF Family/Standard:
Cellular, Navigation, WiFi
Frequency (Center/Band):
657.5MHz, 761MHz, 892MHz, 1.4725GHz, 1.561GHz, 1.575GHz, 1.602GHz, 1.955GHz, 2.495GHz, 2.45GHz, 3.75GHz, 5.5GHz, 5.5375GHz, 6.525GHz
Termination:
RP-SMA Male, SMA Male (2)
standardLeadTime:
6 Weeks
Ingress Protection:
IP65
Features:
Cable - 3m, LNA, Filter
Mounting Type:
Magnetic
Antenna Type:
Dome
Series:
-
Power - Max:
10 W
VSWR:
-
Return Loss:
-10dB
ECCN:
7A994
