Frequency Range:
698MHz ~ 806MHz, 824MHz ~ 894MHz, 880MHz ~ 960MHz, 1.559GHz ~ 1.606GHz, 1.69GHz ~ 1.88GHz, 1.85GHz ~ 1.99GHz, 1.91GHz ~ 2.18GHz, 2.3GHz ~ 2.5GHz, 2.5GHz ~ 2.7GHz, 3.3GHz ~ 3.8GHz
HTSUS:
8529.10.9100
Frequency Group:
Wide Band
Height (Max):
1.890" (48.00mm)
Applications:
3G, 4G, 5G, Beidou, GLONASS, GNSS, GPS, ISM, LTE
Gain:
0.7dBi, 0.5dBi, 0.2dBi, 3.4dBi, 4.9dBi, 5.4dBi, 3.7dBi, 3dBi, 2.5dBi, 3.7dBi, 4.6dBi, 5.5dBi
Number of Bands:
12
Package:
Bulk
RF Family/Standard:
Cellular, General ISM, Navigation
Frequency (Center/Band):
752MHz, 859MHz, 920MHz, 1.561GHz, 1.575GHz, 1.602GHz, 1.785GHz, 1.92GHz, 2.045GHz, 2.4GHz, 2.6GHz, 3.55GHz
Termination:
SMA Male (2)
standardLeadTime:
8 Weeks
Ingress Protection:
IP67
Features:
Cable - 5.18m, LNA
Mounting Type:
Panel Mount
Antenna Type:
Dome
Series:
-
Power - Max:
10 W
VSWR:
2
Return Loss:
-
Base Product Number:
VFT69383
ECCN:
7A994
