Frequency Range:
860MHz ~ 925MHz, 1.9GHz ~ 2.2GHz, 2.4GHz ~ 2.5GHz
HTSUS:
8529.10.9100
RoHS Status:
ROHS3 Compliant
Frequency Group:
UHF (300MHz ~ 1GHz), UHF (2GHz ~ 3GHz)
Height (Max):
0.039" (1.00mm)
REACH Status:
REACH Unaffected
Applications:
3G, Bluetooth, Cellular, GSM, IoT, ISM, Lora, Sigfox, Wi-Fi
Gain:
1.1dBi, 1.3dBi, 2.3dBi, 4.2dBi
Number of Bands:
4
Package:
Bulk
Moisture Sensitivity Level (MSL):
1 (Unlimited)
RF Family/Standard:
Bluetooth, Cellular, General ISM, WiFi
Frequency (Center/Band):
868MHz, 915MHz, 2GHz, 2.45GHz
Termination:
U.FL (UMCC), IPEX MHF1
Ingress Protection:
-
Features:
-
Mounting Type:
Connector Mount
Antenna Type:
PCB Trace
Series:
AN240203
Power - Max:
10 W
VSWR:
2, 3, 2, 3
Return Loss:
-10dB, -6dB, -6dB, -10dB
ECCN:
EAR99
