Frequency Range:
698MHz ~ 960MHz, 1.71GHz ~ 1.99GHz, 1.755GHz ~ 2.17GHz, 2.4GHz ~ 2.5GHz, 2.5GHz ~ 2.69GHz
HTSUS:
8517.71.0000
RoHS Status:
ROHS3 Compliant
Frequency Group:
Wide Band
Height (Max):
0.008" (0.20mm)
REACH Status:
REACH Unaffected
Applications:
4G, 5G, LTE
Gain:
2.4dBi, 4.5dBi, 5.9dBi, 5.9dBi, 4.6dBi, 4dBi
Number of Bands:
6
Package:
Bag
Moisture Sensitivity Level (MSL):
Not Applicable
RF Family/Standard:
Cellular
Frequency (Center/Band):
829MHz, 1.575GHz, 1.85GHz, 1.9625GHz, 2.45GHz, 2.595GHz
Termination:
U.FL (UMCC), IPEX MHF1
standardLeadTime:
12 Weeks
Ingress Protection:
-
Features:
Cable - 150mm
Mounting Type:
Adhesive
Antenna Type:
FlexPIFA
Series:
-
Power - Max:
5 W
VSWR:
-
Return Loss:
-3.4dB, -9.7dB, -9.8dB, -10.5dB, -10.7dB
ECCN:
EAR99
