Minimum Operating Band 2 Frequency:
410MHz
Dimensions:
5.15 x 5.15 x 0.95mm
Mounting Type:
Surface Mount
Minimum Operating Band 3 Frequency:
164MHz
Maximum Operating Temperature:
+85 °C
Maximum Operating Band 3 Frequency:
190MHz
Minimum Operating Supply Voltage:
2 V
Maximum Operating Band 1 Frequency:
950MHz
Height:
0.95mm
Modulation Technique:
FSK, GFSK, MSK, OOK
Width:
5.15mm
Length:
5.15mm
Maximum Operating Band 2 Frequency:
475MHz
Package Type:
VQFN
Minimum Operating Temperature:
-40 °C
Maximum Operating Supply Voltage:
3.6 V
Number of Operating Bands:
3
Minimum Operating Band 1 Frequency:
820MHz
Technology:
Low IF/ISM Transceiver
Pin Count:
32
HTSUS:
8542.39.0001
RoHS Status:
ROHS3 Compliant
Supplier Device Package:
32-VQFN (5x5)
Operating Temperature:
-40°C ~ 85°C
Memory Size:
4kB ROM, 256B RAM
Package / Case:
32-VFQFN Exposed Pad
GPIO:
4
Type:
TxRx + MCU
Current - Transmitting:
33.6mA ~ 54mA
Current - Receiving:
19mA ~ 23.5mA
Modulation:
2FSK, 2GFSK, 4FSK, 4GFSK, MSK, OOK
REACH Status:
REACH Unaffected
Package:
Tape & Reel (TR)
Moisture Sensitivity Level (MSL):
3 (168 Hours)
RF Family/Standard:
General ISM < 1GHz
standardLeadTime:
12 Weeks
Data Rate (Max):
1.25Mbps
Protocol:
-
Mounting Type:
Surface Mount
Series:
-
Sensitivity:
-123dBm
Serial Interfaces:
SPI
Frequency:
164MHz ~ 190MHz, 410MHz ~ 475MHz, 820MHz ~ 950MHz
Voltage - Supply:
2V ~ 3.6V
Power - Output:
16dBm
Base Product Number:
CC1200
ECCN:
5A992C
This is manufactured by Texas Instruments. The manufacturer part number is CC1200RHBT. The given dimensions of the product include 5.15 x 5.15 x 0.95mm. The product is available in surface mount configuration. It has a maximum operating temperature of +85 °c. In addition, the height is 0.95mm. Furthermore, the product is 5.15mm wide. Its accurate length is 5.15mm. Whereas, the minimum operating temperature of the product is -40 °c. This product use low if/ism transceiver technology. It is assigned with possible HTSUS value of 8542.39.0001. The product is rohs3 compliant. 32-vqfn (5x5) is the supplier device package value. The product has -40°c ~ 85°c operating temperature range. It holds a typical memory size of 4kb rom, 256b ram. Moreover, the product comes in [Package/ Case]. It comes in txrx + mcu configuration. It carries 33.6ma ~ 54ma transmission current. The current receiving of the product is 19ma ~ 23.5ma. Features 2fsk, 2gfsk, 4fsk, 4gfsk, msk, ook modulation. In addition, it is reach unaffected. It is shipped in tape & reel (tr). Its typical moisture sensitivity level is 3 (168 hours). The standard RF Family of the product includes general ism < 1ghz. It has a long 12 weeks standard lead time. Robust and maximum data rate speed of 1.25mbps. The sensitivity given includes -123dbm. It features spi serial interface. Supplied with 164mhz ~ 190mhz, 410mhz ~ 475mhz, 820mhz ~ 950mhz of frequency. It has optimum voltage supply of 2v ~ 3.6v. The product has an output power 16dbm. Moreover, it corresponds to cc1200, a base product number of the product. The product is designated with the 5a992c code number
