Supported Protocol:
802.11b/g/n
Dimensions:
21.72 x 14.73 x 3.5mm
Supported Security Standards:
SSL, TLS, WAPI, WEP, WPA, WPA2
Height:
3.5mm
Width:
14.73mm
Length:
21.72mm
Supply Voltage:
2.7 → 3.6V
Minimum Operating Temperature:
-40°C
Supported Bus Interfaces:
I2C, SPI, UART
Maximum Operating Temperature:
+85°C
HTSUS:
8542.31.0001
RoHS Status:
Not applicable
Operating Temperature:
-40°C ~ 85°C
Memory Size:
4MB Flash, 128kB ROM, 64kB RAM
Package / Case:
28-SMD Module
Current - Transmitting:
29mA ~ 230mA
Current - Receiving:
29mA ~ 68mA
Modulation:
16-QAM, 64-QAM, BPSK, CCK, DBPSK, DQPSK, OFDM, QPSK
Data Rate:
72.2Mbps
Package:
Tray
RF Family/Standard:
WiFi
Firmware Version:
19.4.4
Protocol:
802.11b/g/n
Utilized IC / Part:
-
Mounting Type:
Surface Mount
Antenna Type:
Integrated, Trace
Series:
-
Sensitivity:
-98dBm
Serial Interfaces:
I²C, SPI, UART
Frequency:
2.4GHz
Voltage - Supply:
2.7V ~ 3.6V
Power - Output:
19dBm
ECCN:
5A992C
