Mounting Type:
Through Hole
Diode Technology:
Silicon Junction
Peak Reverse Recovery Time:
85ns
Peak Non-Repetitive Forward Surge Current:
800A
Maximum Forward Voltage Drop:
1.6V
Maximum Continuous Forward Current:
80A
Rectifier Type:
Switching
Package Type:
TO-247
Number of Elements per Chip:
1
Diode Type:
Rectifier
Diode Configuration:
Single
Pin Count:
2
Peak Reverse Repetitive Voltage:
600V
HTSUS:
8541.10.0080
RoHS Status:
ROHS3 Compliant
Package / Case:
TO-247-2
Operating Temperature - Junction:
-65°C ~ 175°C
REACH Status:
REACH Unaffected
Reverse Recovery Time (trr):
85 ns
Current - Average Rectified (Io):
80A
Speed:
Fast Recovery =< 500ns, > 200mA (Io)
Voltage - Forward (Vf) (Max) @ If:
1.6 V @ 80 A
Package:
Tube
Voltage - DC Reverse (Vr) (Max):
600 V
Capacitance @ Vr, F:
-
Moisture Sensitivity Level (MSL):
Not Applicable
Current - Reverse Leakage @ Vr:
250 µA @ 600 V
Mounting Type:
Through Hole
Series:
-
Supplier Device Package:
TO-247-2
Technology:
Standard
Base Product Number:
RURG80
ECCN:
EAR99
