Dimensions:
10 x 5.65 x 6.5mm
Electrical Life:
10^5 Operations
Application:
Signal
Terminal Type:
Through Hole
Coil Resistance:
178Ω
Life:
100000 (Electrical) Operations, 100000000 (Mechanical) Operations
Standards Met:
cULus E133481, RoHS Compliant
Coil Power:
140mW
Maximum Switching Voltage DC:
220V
Maximum Switching Power DC:
60 W
Isolation Coil To Contact:
1.6kV ac
Maximum Operating Temperature:
+85°C
Switching Current:
2A
Maximum Switching Current AC:
2 A
Coil Voltage:
5V dc
Operating Temperature Range:
-40 → +85°C
Latching:
No
Contact Configuration:
SPDT
Depth:
6.5mm
Relay Switching Classification:
Subminiature Signal Relay
Features:
High Contact Capacity, Low Power Consumption
Mounting Type:
PCB Mount
Length:
10mm
Height:
5.65mm
Maximum Switching Current DC:
2 A
Maximum Switching Voltage AC:
250V
Minimum Operating Temperature:
-40°C
Maximum Switching Power AC:
60VA
Number of Poles:
2
Contact Material:
Gold Plated, Rhodium Plated Palladium Nickel
