Mounting Type:
Surface Mount
Maximum Continuous Forward Current:
2A
Package Type:
DO-214AC (SMA)
Number of Elements per Chip:
1
Diode Configuration:
Single
Pin Count:
2
Peak Reverse Repetitive Voltage:
200V
HTSUS:
8541.10.0080
RoHS Status:
ROHS3 Compliant
Package / Case:
DO-214AC, SMA
Operating Temperature - Junction:
175°C
REACH Status:
REACH Unaffected
Reverse Recovery Time (trr):
30 ns
Current - Average Rectified (Io):
2A
Speed:
Fast Recovery =< 500ns, > 200mA (Io)
Voltage - Forward (Vf) (Max) @ If:
1.04 V @ 2 A
Package:
Tape & Reel (TR)
Voltage - DC Reverse (Vr) (Max):
200 V
Capacitance @ Vr, F:
-
Moisture Sensitivity Level (MSL):
1 (Unlimited)
standardLeadTime:
45 Weeks
Current - Reverse Leakage @ Vr:
2.5 µA @ 200 V
Mounting Type:
Surface Mount
Series:
Automotive, AEC-Q101, ECOPACK®2
Supplier Device Package:
SMA (DO-214AC)
Technology:
Standard
ECCN:
EAR99
