Dimensions:
16.05 x 14 x 5.1mm
Mounting Type:
Surface Mount
Maximum Collector Emitter Voltage:
1200 V
Maximum Continuous Collector Current:
50 A
Package Type:
TO-268
Minimum Operating Temperature:
-55 °C
Maximum Operating Temperature:
+150 °C
Pin Count:
3
Transistor Configuration:
Single
HTSUS:
8541.29.0095
RoHS Status:
ROHS3 Compliant
Switching Energy:
3.47mJ (on), 2.16mJ (off)
Vce(on) (Max) @ Vge, Ic:
3.5V @ 15V, 30A
Voltage - Collector Emitter Breakdown (Max):
1200 V
Td (on/off) @ 25°C:
16ns/127ns
Operating Temperature:
-55°C ~ 150°C (TJ)
Input Type:
Standard
Package / Case:
TO-268-3, D³Pak (2 Leads + Tab), TO-268AA
Gate Charge:
87 nC
Reverse Recovery Time (trr):
100 ns
REACH Status:
REACH Unaffected
Test Condition:
960V, 30A, 5Ohm, 15V
Package:
Tube
Moisture Sensitivity Level (MSL):
1 (Unlimited)
standardLeadTime:
64 Weeks
IGBT Type:
PT
Current - Collector Pulsed (Icm):
150 A
Mounting Type:
Surface Mount
Series:
GenX3™
Supplier Device Package:
TO-268AA
Power - Max:
300 W
Base Product Number:
IXGT30
ECCN:
EAR99
