Schneider Electric 2 A SPNO Solid State Relay, AC Switching, PCB Mount SCR, 280 V ac Maximum Load

SSL1A12BD Schneider Electric 2 A SPNO Solid State Relay, AC Switching, PCB Mount SCR, 280 V ac Maximum Load
SSL1A12BD
SSL1A12BD
ET13815549
Schneider Electric

Product Information

Dimensions:
28 x 5 x 15mm
Relay Type:
Single Phase
Capacitance:
1.5pF
Range:
Harmony
Maximum Load Voltage:
280 V ac
Output Device:
SCR
Load Voltage Range:
24 → 280V ac
Standards Met:
CE, CSA, UL
Minimum Control Voltage:
15 V dc
Off State Leakage Current:
4 mA
Switching Type:
AC
Maximum Operating Temperature:
+80°C
Terminal Type:
PCB Pin
Control Voltage Range:
15 → 30 V dc
Operating Temperature Range:
-20 → +80°C
Minimum Load Current:
0.07 A
Contact Configuration:
SPST
Length:
28mm
Maximum Turn On Time:
1/2 cycle
Special Features:
Built-In Diode Protection Circuit & LED Indicator, Mounted on Universal AC/DC Sockets, Slim Interface SSL Relays with PCB Terminals
Maximum Load Current:
2 A
Better World Verification:
Green Premium
Better World Product:
Yes
Mounting Type:
PCB Mount
Depth:
5mm
Height:
15mm
Minimum Operating Temperature:
-20°C
Maximum Control Voltage:
30 V dc
Number of Poles:
1
Minimum Load Voltage:
24 V ac
Checking for live stock

This is 2 A SPNO Solid State Relay AC Switching PCB Mount SCR 280 V ac Maximum Load manufactured by Schneider Electric. The manufacturer part number is SSL1A12BD. The given dimensions of the product include 28 x 5 x 15mm. This is basically a single phase. It provides a 1.5pf of capacitance value. It has a maximum operating temperature of +80°c. The terminal is a pcb pin type. Its accurate length is 28mm. The product is available in pcb mount configuration. The product comes in 5mm depth. In addition, the height is 15mm. Whereas, the minimum operating temperature of the product is -20°c. It has equipped with 1 poles.
