Dimensions:
22.5 x 53.1 x 91.9mm
Relay Type:
Control Relay
Capacitance:
8pF
Range:
NOVA22
Maximum Load Voltage:
280 V ac
Load Voltage Range:
90 → 280V ac
Standards Met:
CE, CSA C22.2 No. 14, cULus Recognised E116949, EMC Compliant, IEC, IEC 60068-2-27, IEC 60068-2-6, UL, UL 94 V-0
Minimum Control Voltage:
0 V dc
Off State Leakage Current:
4mArms
Switching Type:
Burst Fire Control, Phase Angle
Maximum Operating Temperature:
+70°C
Terminal Type:
Screw
Control Voltage Range:
Operating Temperature Range:
-25 → +70°C
Minimum Load Current:
100mA rms
Length:
22.5mm
Maximum Turn On Time:
20 cycles
Special Features:
LED Multifunction Status Indicator
Maximum Load Current:
50 A
Mounting Type:
Panel Mount
Series:
PMP
Depth:
53.1mm
Height:
91.9mm
Minimum Operating Temperature:
-25°C
Maximum Control Voltage:
10 V dc
Number of Poles:
1
Minimum Load Voltage:
90 V ac
HTSUS:
8536.49.0080
Termination Style:
Screw Terminal
Package / Case:
Module
Voltage - Input:
4 ~ 20mA, 0 ~ 10VDC
Load Current:
50 A
Output Type:
AC, Proportional Control
Package:
Bulk
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Circuit:
SPST-NO (1 Form A)
standardLeadTime:
31 Weeks
Mounting Type:
Chassis Mount
Series:
PMP
Voltage - Load:
90 V ~ 280 V
Supplier Device Package:
-
Base Product Number:
PMP2450
ECCN:
EAR99
