Vishay IHLP6767GZ-11 Series Type 6767 Shielded Wire-wound SMD Inductor with a Metal Composite Core, 10 μH ±20%

IHLP6767GZER100M11 Vishay IHLP6767GZ-11 Series Type 6767 Shielded Wire-wound SMD Inductor with a Metal Composite Core, 10 μH ±20%
Vishay

Product Information

Maximum DC Resistance:
9.33mΩ
Inductor Construction:
Shielded
Dimensions:
17.15 x 17.15 x 7mm
Shielded:
Yes
Series:
IHLP
Length:
17.15mm
Height:
7mm
Maximum DC Current:
19A
Depth:
17.15mm
Core Material:
Metal Composite
Inductance:
10 μH
Maximum Self Resonant Frequency:
8MHz
Maximum Operating Temperature:
+125°C
Tolerance:
±20%
Minimum Operating Temperature:
-55°C
Package/Case:
6767
RoHs Compliant
Checking for live stock

This is IHLP6767GZ-11 Series Type 6767 Shielded Wire-wound SMD Inductor with a Metal Composite Core 10 μH ±20% manufactured by Vishay. The manufacturer part number is IHLP6767GZER100M11. The given dimensions of the product include 17.15 x 17.15 x 7mm. The product ihlp, is a highly preferred choice for users. Its accurate length is 17.15mm. In addition, the height is 7mm. The product comes in 17.15mm depth. The product has a 10 μh inductance value. It has a maximum operating temperature of +125°c. It features ±20% of tolerance value. Whereas, the minimum operating temperature of the product is -55°c.

pdf icon
Application Note(Technical Reference)
pdf icon
Power Inductors Capabilities(Technical Reference)
pdf icon
Power Inductors 101(Technical Reference)
pdf icon
Datasheet(Technical Reference)
pdf icon
Did You Know?(Technical Reference)
pdf icon
IHLP Selection Example(Technical Reference)
pdf icon
Power Inductors Infograph(Technical Reference)
