Vishay IHLP-3232DZ-11 Series Type 3232 Shielded Wire-wound SMD Inductor With A Metal Composite Core, 2.2 μH ±20%

IHLP3232DZER2R2M11 Vishay IHLP-3232DZ-11 Series Type 3232 Shielded Wire-wound SMD Inductor with a Metal Composite Core, 2.2 μH ±20%

(0)

Product Information

Maximum DC Resistance:

9.41mΩ

Inductor Construction:

Wire-Wound

Dimensions:

8.64 x 8.18 x 4mm

Shielded:

Yes

Series:

IHLP-3232DZ-11

Length:

8.64mm

Height:

4mm

Maximum DC Current:

14.5A

Depth:

8.18mm

Core Material:

Metal Composite

Inductance:

2.2 μH

Maximum Self Resonant Frequency:

25MHz

Checking for live stock

This is IHLP-3232DZ-11 Series Type 3232 Shielded Wire-wound SMD Inductor with a Metal Composite Core 2.2 μH ±20% manufactured by Vishay. The manufacturer part number is IHLP3232DZER2R2M11. The given dimensions of the product include 8.64 x 8.18 x 4mm. The product ihlp-3232dz-11, is a highly preferred choice for users. Its accurate length is 8.64mm. In addition, the height is 4mm. The product comes in 8.18mm depth. The product has a 2.2 μh inductance value. It has a maximum operating temperature of +125°c. It features ±20% of tolerance value. Whereas, the minimum operating temperature of the product is -55°c.
