Impulse Discharge Current:
12.5kA
Dimensions:
99 x 71.2 x 77.5mm
Operating Temperature Range:
-40 → +80 °C
Device Type:
Surge Arrestor
Series:
VAL-MS-T1/T2 335/12.5/3+1-FM
Voltage Protection Rating:
250V ac
Length:
99mm
Mounting Style:
DIN Rail
Width:
71.2mm
Depth:
77.5mm
Minimum Operating Temperature:
-40°C
Electrical Phase:
3
Maximum Surge Current:
50kA
Maximum Operating Temperature:
+80°C
HTSUS:
8536.30.8000
RoHS Status:
RoHS Compliant
Voltage - Continuous Operating (Max) (MCOV):
670VAC
Operating Temperature:
-40°C ~ 80°C
Approval Agency:
CB, CCA, cUL, cULus,EAC, GL, KEMA-KEUR, OVE, UL
Type:
Type 1, Type 2
Current - Short Circuit Rating (SCRR):
25 kA
Form:
Module Only
Voltage - Protection Level (VP) (2416):
2 kV
Package:
Bulk
Moisture Sensitivity Level (MSL):
1 (Unlimited)
standardLeadTime:
4 Weeks
Features:
Remote Signaling Contacts
Mounting Type:
DIN Rail
Series:
-
Current - Discharge (Nom) (8/20µS):
50 kA
Number of Poles:
4
ECCN:
EAR99
