Diameter:
2.7mm
Dimensions:
2.7 (Dia.) x 5.2mm
Mounting Type:
Through Hole
Maximum Operating Temperature:
+175 °C
Maximum Forward Voltage Drop:
1.75V
Height:
5.2mm
Diode Technology:
Silicon Junction
Package Type:
DO-41
Number of Elements per Chip:
1
Minimum Operating Temperature:
-65 °C
Diode Configuration:
Single
Pin Count:
2
HTSUS:
8541.10.0080
RoHS Status:
ROHS3 Compliant
Package / Case:
DO-204AL, DO-41, Axial
Reverse Recovery Time (trr):
100 ns
Operating Temperature - Junction:
-65°C ~ 175°C
REACH Status:
REACH Unaffected
Current - Average Rectified (Io):
1A
Speed:
Fast Recovery =< 500ns, > 200mA (Io)
Voltage - Forward (Vf) (Max) @ If:
1.75 V @ 1 A
Package:
Bulk
Voltage - DC Reverse (Vr) (Max):
1000 V
Capacitance @ Vr, F:
-
Moisture Sensitivity Level (MSL):
Not Applicable
standardLeadTime:
51 Weeks
Current - Reverse Leakage @ Vr:
10 µA @ 1000 V
Mounting Type:
Through Hole
Series:
SWITCHMODE™
Supplier Device Package:
Axial
Technology:
Standard
Base Product Number:
MUR1100
ECCN:
EAR99
