Switch Operation:
Off-On (Momentary)
Operating Force:
1.76 N
Actuator Length:
3mm
Illuminated:
Yes
Mounting Type:
PCB
Voltage Rating:
24V dc
Contact Current Rating:
50 mA
Minimum Operating Temperature:
-25°C
Contact Configuration:
Single Pole Single Throw (SPST)
Height:
11.2mm
Width:
12mm
Length:
12mm
Actuator Type:
Short
Operating Temperature Range:
-25 → +70°C
Contact Material:
Brass (Stationary), Stainless Steel (Movable)
Maximum Operating Temperature:
+70°C
Terminal Type:
PC Pin
Dimensions:
10 x 10 x 11.20mm
Operating Force:
176gf
HTSUS:
8536.50.9031
RoHS Status:
ROHS3 Compliant
Termination Style:
PC Pin
Actuator Height off PCB, Vertical:
-
Operating Temperature:
-25°C ~ 70°C
Actuator Orientation:
Top Actuated
Mechanical Life:
5,000,000 Cycles
REACH Status:
REACH Unaffected
Illumination Type, Color:
LED, Green
Outline:
10.00mm x 10.00mm
Package:
Tray
Switch Function:
Off-Mom
Actuator Length, Right Angle:
-
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Circuit:
SPST-NO
Contact Rating @ Voltage:
0.05A @ 24VDC
standardLeadTime:
30 Weeks
Ingress Protection:
IP67 - Dust Tight, Waterproof
Features:
Process Sealed
Mounting Type:
Through Hole
Series:
JB
Switch Travel:
0.25mm
Actuator Type:
Plunger for Cap
Illumination:
Illuminated
Illumination Voltage (Nominal):
2.1 VDC
Actuator Material:
-
Base Product Number:
-
ECCN:
EAR99
