Time Delay:
(Reset) 120ms
Time Increment:
Hours, Minutes, Seconds
Mounting Type:
DIN Rail
Maximum Current:
16A
Time Range:
0.1 s → 100h
Power Supply:
External
Length:
23.2mm
Mode of Operation:
AD, AH, N, O, P, Pt, TI, Tt, W
Width:
90mm
Depth:
90mm
Supply Voltage:
24 V dc, 24 → 240V ac
Minimum Operating Temperature:
-20°C
Number of Timer Functions:
Multi Function
Switch Configuration:
2 C/O
Number of Contacts:
2
Maximum Operating Temperature:
+60°C
Terminal Type:
Screw
Contact Material:
Silver Nickel
HTSUS:
8536.49.0075
RoHS Status:
RoHS Compliant
Relay Type:
Mechanical Relay
Termination Style:
Screw Terminal
Timing Initiate Method:
Input Voltage, Trigger Signal
Function:
Programmable (Multi-Function)
REACH Status:
REACH Unaffected
Package:
Bulk
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Circuit:
DPDT (2 Form C)
Contact Rating @ Voltage:
8A @ 250VAC
standardLeadTime:
3 Weeks
Delay Time:
0.1 Sec ~ 100 Hrs
Timing Adjustment Method:
Screwdriver Slot
Mounting Type:
DIN Rail
Series:
RX2R1
Voltage - Supply:
24 ~ 240VAC, 24VDC
ECCN:
EAR99
