Maximum Voltage:
240V ac/dc
Width:
48mm
Supply Voltage:
100 → 240V ac/dc
Maximum Current:
5A
Time Range:
0.001 → 9.999 s, 0.01 → 99.99 s, 0.1 → 999.9 min, 0.1 → 999.9 s, 0.1 → 999.9 h, 1 min → 99 h 59 min, 1 s → 99 min 59 s, 1 → 9999 h, 1 → 9999 s, 1 → 9999min
Mode of Operation:
Interval, OFF Delay (Delay on Break), ON Delay (Delay on Make), One Shot, Symmetrical Flashing (OFF Start), Symmetrical Flashing (ON Start)
Number of Timer Functions:
Multi Function
Maximum Operating Temperature:
+60°C
Terminal Type:
Plug In
Time Increment:
Hours, Minutes, Seconds
Power Supply:
External
Switch Configuration:
SPDT
Contact Configuration:
SPDT
Length:
48mm
Minimum Voltage:
100V ac/dc
Mounting Type:
Panel Mount
Series:
Syr-Line
Depth:
68mm
Minimum Current:
3A
Minimum Operating Temperature:
-10°C
Number of Contacts:
1
HTSUS:
9107.00.8000
RoHS Status:
RoHS Compliant
Termination Style:
Plug In, 8 Pin (Octal)
Timing Initiate Method:
Input Voltage
Function:
Programmable (Multi-Function)
REACH Status:
REACH Unaffected
Package:
Box
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Circuit:
SPDT (1 Form C)
Contact Rating @ Voltage:
5A @ 250VAC
standardLeadTime:
3 Weeks
Delay Time:
0.001 Sec ~ 9999 Hrs
Timing Adjustment Method:
Up/Down Digit Keys
Mounting Type:
Socketable
Series:
TMR48D
Voltage - Supply:
100 ~ 240VAC/DC
ECCN:
EAR99
