Maximum Operating Temperature:
+60°C
Time Delay:
0.5s
Maximum Current:
10A
Mounting Type:
Plug In
Maximum Voltage:
240V ac/dc
Series:
OU1R
Time Range:
0.05 → 1 min, 0.05 → 1 days, 0.05 → 1 h, 0.5 → 10 s, 0.5 → 10 min, 0.5 → 10 h, 0.5 → 10days
Length:
35mm
Mode of Operation:
Interval
Contact Configuration:
SPDT
Width:
82.31mm
Depth:
53mm
Supply Voltage:
12 → 240V ac/dc
Minimum Operating Temperature:
-20°C
Number of Timer Functions:
Multi Function
Minimum Voltage:
12V ac/dc
Number of Contacts:
1
Switch Configuration:
SPDT
Terminal Type:
Plug In
HTSUS:
9107.00.8000
Relay Type:
Mechanical Relay
Termination Style:
Plug In, 8 Pin (Octal)
Timing Initiate Method:
Input Voltage, Trigger Signal
Function:
Programmable (Multi-Function)
REACH Status:
REACH Unaffected
Package:
Box
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Circuit:
SPDT (1 Form C)
Contact Rating @ Voltage:
10A @ 250VAC
standardLeadTime:
3 Weeks
Delay Time:
0.5 Sec ~ 240 Hrs
Timing Adjustment Method:
Hand Dial
Mounting Type:
Socketable
Series:
OU1R10
Voltage - Supply:
12 ~ 240VAC/DC
ECCN:
EAR99
