Maximum Low Level Output Current:
50mA
Dimensions:
6.6 x 4.5 x 1.05mm
Mounting Type:
Surface Mount
Maximum Propagation Delay Time @ Maximum CL:
0.34 ns @ -3 V, -5.5 V ns @ 5.5 V
Minimum Operating Supply Voltage:
±3 V
Logic Function:
Translator
Logic Family:
ECL
Package Type:
TSSOP
Minimum Operating Temperature:
-40 °C
Maximum Operating Supply Voltage:
±5.5 V
Translation:
ECL, LVECL to LVPECL, PECL
Maximum Operating Temperature:
+85 °C
Pin Count:
20
Maximum High Level Output Current:
-50mA
Translator Type:
Mixed Signal
HTSUS:
8542.39.0001
RoHS Status:
ROHS3 Compliant
Output Signal:
PECL, LVPECL
Operating Temperature:
-40°C ~ 85°C (TA)
Package / Case:
20-TSSOP (0.173", 4.40mm Width)
Input Signal:
ECL
REACH Status:
REACH Unaffected
Output Type:
Differential
Data Rate:
-
Package:
Tube
Channel Type:
Unidirectional
Moisture Sensitivity Level (MSL):
1 (Unlimited)
standardLeadTime:
28 Weeks
Number of Circuits:
1
Channels per Circuit:
3
Features:
-
Mounting Type:
Surface Mount
Series:
100EP
Supplier Device Package:
20-TSSOP
Base Product Number:
100EP90
ECCN:
EAR99
