Maximum Low Level Output Current:
7.8mA
Dimensions:
5.1 x 4.5 x 1.05mm
Mounting Type:
Surface Mount
Maximum Propagation Delay Time @ Maximum CL:
135 ns @ 50 pF
Minimum Operating Supply Voltage:
2 V
Logic Function:
Buffer
Propagation Delay Test Condition:
50pF
Output Type:
3 State
Automotive Standard:
AEC-Q100
Maximum High Level Output Current:
7.8mA
Package Type:
TSSOP
Logic Family:
HC
Minimum Operating Temperature:
-55 °C
Maximum Operating Supply Voltage:
2 to 6 V
Maximum Operating Temperature:
+125 °C
Pin Count:
14
Number of Elements per Chip:
1
HTSUS:
8542.39.0001
RoHS Status:
ROHS3 Compliant
Operating Temperature:
-55°C ~ 125°C (TA)
Input Type:
-
Package / Case:
14-TSSOP (0.173", 4.40mm Width)
Number of Bits per Element:
1
REACH Status:
REACH Unaffected
Output Type:
3-State
Package:
Tape & Reel (TR)
Moisture Sensitivity Level (MSL):
1 (Unlimited)
standardLeadTime:
28 Weeks
Mounting Type:
Surface Mount
Series:
74HC
Logic Type:
Buffer, Non-Inverting
Supplier Device Package:
14-TSSOP
Voltage - Supply:
2V ~ 6V
Current - Output High, Low:
7.8mA, 7.8mA
Number of Elements:
4
Base Product Number:
74HC125
ECCN:
EAR99
