Maximum Low Level Output Current:
7.8mA
Dimensions:
12.95 x 7.6 x 2.4mm
Mounting Type:
Surface Mount
Maximum Propagation Delay Time @ Maximum CL:
225 ns @ 50 pF
Propagation Delay Test Condition:
50pF
Minimum Operating Supply Voltage:
2 V
Output Type:
3 State
Automotive Standard:
AEC-Q100
Maximum High Level Output Current:
7.8mA
Package Type:
SOIC
Logic Family:
HC
Minimum Operating Temperature:
-55 °C
Maximum Operating Supply Voltage:
2 to 6 V
Maximum Operating Temperature:
+125 °C
Pin Count:
20
Number of Elements per Chip:
1
HTSUS:
8542.39.0001
RoHS Status:
ROHS3 Compliant
Operating Temperature:
-55°C ~ 125°C
Package / Case:
20-SOIC (0.295", 7.50mm Width)
Delay Time - Propagation:
26ns
REACH Status:
REACH Unaffected
Output Type:
Tri-State
Independent Circuits:
1
Package:
Tape & Reel (TR)
Moisture Sensitivity Level (MSL):
3 (168 Hours)
Circuit:
8:8
standardLeadTime:
29 Weeks
Mounting Type:
Surface Mount
Series:
74HC
Logic Type:
D-Type Transparent Latch
Supplier Device Package:
20-SOIC
Voltage - Supply:
2V ~ 6V
Current - Output High, Low:
7.8mA, 7.8mA
Base Product Number:
74HC573
ECCN:
EAR99
