Maximum Low Level Output Current:
6mA
Dimensions:
12.95 x 7.6 x 2.4mm
Mounting Type:
Surface Mount
Maximum Propagation Delay Time @ Maximum CL:
45 ns @ 50 pF
Propagation Delay Test Condition:
50pF
Minimum Operating Supply Voltage:
4.5 V
Output Type:
3 State
Maximum High Level Output Current:
6mA
Package Type:
SOIC
Logic Family:
HCT
Minimum Operating Temperature:
-55 °C
Maximum Operating Supply Voltage:
5.5 V
Maximum Operating Temperature:
+125 °C
Pin Count:
20
Number of Elements per Chip:
1
HTSUS:
8542.39.0001
RoHS Status:
ROHS3 Compliant
Operating Temperature:
-55°C ~ 125°C
Package / Case:
20-SOIC (0.295", 7.50mm Width)
Delay Time - Propagation:
30ns
REACH Status:
REACH Unaffected
Output Type:
Tri-State
Independent Circuits:
1
Package:
Tube
Moisture Sensitivity Level (MSL):
3 (168 Hours)
Circuit:
8:8
standardLeadTime:
32 Weeks
Mounting Type:
Surface Mount
Series:
74HCT
Logic Type:
D-Type Transparent Latch
Supplier Device Package:
20-SOIC
Voltage - Supply:
4.5V ~ 5.5V
Current - Output High, Low:
6mA, 6mA
Base Product Number:
74HCT573
ECCN:
EAR99
