Maximum Clamping Voltage:
13.7V
Maximum Peak Pulse Current:
3A
Maximum Reverse Stand-off Voltage:
5V
Dimensions:
1.4 x 0.9 x 0.35mm
Mounting Type:
Surface Mount
Capacitance:
0.76pF
Maximum Reverse Leakage Current:
50 nA, 70 nA
Maximum Operating Temperature:
+150 °C
Minimum Breakdown Voltage:
5.7V
Direction Type:
Uni-Directional
Height:
0.35mm
Width:
0.9mm
Length:
1.4mm
Package Type:
μDFN
Number of Elements per Chip:
4
Minimum Operating Temperature:
-40 °C
ESD Protection:
Yes
Working Voltage:
5V
Diode Configuration:
Array
Pin Count:
5
Voltage - Clamping (Max) @ Ipp:
11.3V
HTSUS:
8541.10.0080
RoHS Status:
ROHS3 Compliant
Operating Temperature:
-40°C ~ 150°C (TJ)
Package / Case:
5-XFDFN
Type:
Steering (Rail to Rail)
REACH Status:
REACH Unaffected
Voltage - Breakdown (Min):
5.7V
Applications:
HDMI, USB
Package:
Tape & Reel (TR)
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Unidirectional Channels:
4
standardLeadTime:
45 Weeks
Current - Peak Pulse (10/1000µs):
3A (8/20µs)
Voltage - Reverse Standoff (Typ):
5V (Max)
Mounting Type:
Surface Mount
Series:
HSP
Supplier Device Package:
5-µQFN (1.3x0.8)
Capacitance @ Frequency:
0.6pF @ 200MHz ~ 2.5GHz
Power Line Protection:
Yes
Power - Peak Pulse:
-
Base Product Number:
HSP051
ECCN:
EAR99
