Cinch

0 Followers

5.0 / 5

Reviews 1 Outstanding

Cinch Profile

CINCH Connectors is a UK-based subsidiary private company of Cinch Connectivity Solutions, founded in 1987, that manufactures, designs, and markets an extensive range of interconnect products worldwide. For over 30 years, the company has been providing robust and high-quality cylindrical connectors, indicators, enclosures, crimping tools, server racks, and kits for global customers at reasonable prices. CINCH products are extensively used in industrial markets such as transportation, telecommunication, electronics, computers, military & defense, and aircraft. The company also provides connectivity solutions across different countries through leading distributor partnerships.

Website
Manufacturer Type
Company Size
Location
Founded
Specialties

Reviews

5 star

(100%)

4 star

(0%)

3 star

(0%)

2 star

(0%)

1 star

(0%)

Rate

Comment

Jonny Lee Miller

20 Jan, 2023

A company that cares. Top quality and fair prices. A family of products to last a long time. Best of Luck Cinch!

Don’t hesitate to ask questions for better clarification.

Featured Products

All Products

145-0801-602, Cinch

The Johnson 2.92mm Series Connector provides an excellent solution for demanding applications requiring high frequency transmission. Although sim...

SHOW DETAILS

RS000300000EL1K, Cinch

Straight PCB Connectors Note Straight PCB filter 'D' has OL2 contact tail (10.2mm) from the lip of the rear shell fla...

SHOW DETAILS

JA778460000E000, Cinch

Standard Multipole Connectors Low loss mouldings with bright tin plated contacts Max working voltage 636Vac...

SHOW DETAILS

50-31SNL-XTF, Cinch

0.1in (2.54mm) PCB Edge Connectors (IBM PC AT™) 18, 31 and 18 + 31 way 0.1in. edge connectors IBM PC AT™ co...

SHOW DETAILS

FDAB-15P1AENTI2/1-LF, Cinch

90° PCB Connectors Integral discrete capacitive elements provide protection against EMI/RFI interference Meets MIL -STD-220 attenuation standard...

SHOW DETAILS

5810130045, Cinch

Modice Headers Interfaces with Cinch SHS, industry standard harness connectors Features and Benefits...

SHOW DETAILS

RS000170000EL1K, Cinch

Cinch Filter D-sub Plug and Socket Connectors with Solder Bucket Terminals Filter D-Sub plug and socket connectors...

SHOW DETAILS

27-8110, Cinch

BNC Connector Adapters A range of BNC coaxial connector adapters from Cinch that are designed for use with applications such as test equipment an...

SHOW DETAILS

142-0701-401, Cinch

SMA Cable Connectors Cinch Connectivity range of professional grade crimp or solder cable mount SMA connectors have a stainless steel body and go...

SHOW DETAILS

415-0072-006, Cinch

SMA Cable Assembly Cinch Connectivity professional range of RF coaxial cable assemblies with a variety of RF coaxial connectors and cable types.

SHOW DETAILS

415-0081-006, Cinch

SMA Cable Assembly Cinch Connectivity professional range of RF coaxial cable assemblies with a variety of RF coaxial connectors and cable types.

SHOW DETAILS

BA000010000CE00, Cinch

0.1in (2.54mm) PCB Edge Connectors (IBM PC AT™) 18, 31 and 18 + 31 way 0.1in. edge connectors IBM PC AT™ compatible 30μ in gold plated, double ro...

SHOW DETAILS

Popular Categories For Cinch

D Sub Connectors (24)

Insertion & Extraction Tools (4)

Coaxial Adapters (7)

Automotive Connectors (11)

Coaxial Cable (39)

Crimp Tools (8)

Ethernet Cable (12)

Edge Connectors (6)

Coaxial Connectors (34)

D Sub Adapters (4)

D Sub Backshells (6)

Automotive Connector Backshells (4)

Categories For Cinch

Cables & Wires (39)

Coaxial Cable (39)

Network Test & Measurement (1)

Network Testers (1)

Popular Items

Popular items

145-0801-602, Cinch

The Johnson 2.92mm Series Connector provides an excellent solution for demanding applications requiring high frequency transmission. Although similar to the SMA interface, a smaller internal body diameter (2.92mm) and air dielectric provide a higher cutoff frequency and other key advantages Superior electrical performance to 40 GHz Female contacts have a unique three-slot construction Mating interface control provides consistent electrical performance

Product Detail

Popular items

RS000300000EL1K, Cinch

Straight PCB Connectors Note Straight PCB filter 'D' has OL2 contact tail (10.2mm) from the lip of the rear shell flange Standards CECC-73301-802; MIL-C-24308; DIN-14652; BS-9523; F0013; BT-217; HE-501 Standards CECC-73301-802; MIL-C-24308; DIN-41652; BS-9523; F0013; BT-217; HE-501 Cinch Filtered 'D' Connectors Solder termination connection Designed to limit cable borne EMI via a 1000pF capacitor from each contact to ground Enhances rejection levels in VHF & UHF bands Bright tin finish on steel backshells shields against RFI/EM and the potted construction allows use in hazardous environments Gold plated turned pin contacts High quality machined contact Flammability rating: UL94V-0 Suitable for military, industrial or commercial applications and computer interfacing etc

Product Detail

Popular items

JA778460000E000, Cinch

Standard Multipole Connectors Low loss mouldings with bright tin plated contacts Max working voltage 636Vac/900Vdc at 5A (enclosed use only, derate to 35Vac rms/50Vdc when openly accessible and connection/disconnection is possible without the use of a tool Plugs and sockets can be chassis mounted Interchangeable moulded cover shells (non-reversible) and retaining clips for cable mounting are available separately Initial Contact Resistance 1.5mΩ max. Test Voltage 2.8kVdc Min. Insulation Resistance at 5000Vdc 10 16 Ω Capacitance Pin-pin and Pin-frame 2.5pF Temperature Range -40°C to +100°C Dimensions (mm) No. of ways 4 8 12 20 A ±0.13 32.9 32.9 32.9 32.9 B ±0.13 12.7 22.3 C -0.00 +0.25 26.9 26.9 26.9 26.9 D -0.00 +0.25 7.6 13.2 18.7 29.7 Cable entry hole dia. 7.8 8.9 11.1 13.0 Height 35 35 35 35 Depth 41 41 41 41 Width 13 18 24 35 Note Cover shells are supplied with fixing screws, cable clamp and retaining spring. Metal parts, except contacts, are corrosion resistant.

Product Detail

Popular items

50-31SNL-XTF, Cinch

0.1in (2.54mm) PCB Edge Connectors (IBM PC AT™) 18, 31 and 18 + 31 way 0.1in. edge connectors IBM PC AT™ compatible 30μ in gold plated, double row contacts UL94V-0 rated polyester insulation 0.156in. (3.96mm) dip solder tails Polarising key supplied Temp rating -65 to 125°C Edge Connectors - Cinch Gold-flashed or gold-plated contacts. Glass-filled diallyl phthalate mouldings. Single-sided types have backing contacts.,Metal feet types Single- and double-sided edge connectors with removable metal feet. 32-way type supplied with polarising key. 43-way types have position 37 fitted with a polarising key. Dimensions Dimensions Information 0.156 in. 0.15 in. 0.1 in. 0.1 in. (IBM PC AT™) No of Ways 18 22 8 12 16 16 24 32 40 43 18 31 18//31 Card Aperture (mm) 75.5 91.3 34.3 49.5 64.8 41.5 61.8 82.1 102.4 - 48.2 81.3 135 Fixing Centres (mm) 86.5 102.3 45.7 61 76.2 59.4 79.8 100 120.4 124.2 - - 7777 (96*) Overall Length (mm) 92.9 108.7 53 69 84 68 89 109 129 133 52.3 85.3 139 (105*) Card Insertion (mm) 10.5 10.5 7.5 7.5 7.5 8.5 8.5 8.5 8.5 8.5 7.6 7.6 7.6 Depth (mm) (7.9*) (7.9*) (7.9*) (7.9*) Connector Width (mm) 10 max. 10 max. 8.7 8.7 8.7 10.2 10.2 10.2 10.2 10.2 9.14 9.14 9.14 Fixing Hole Dia. (mm) 3.2 Slotted 3.2 Slotted 3.2 3.2 3.2 3.2 Slotted - - - * Wire-wrapping type

Product Detail

Popular items

FDAB-15P1AENTI2/1-LF, Cinch

90° PCB Connectors Integral discrete capacitive elements provide protection against EMI/RFI interference Meets MIL -STD-220 attenuation standard Interchangeable with standard 90° connectors High quality machined contacts 1000 pf Ceramic capacitor filtration Shell material Steel, tin Insulator material Polyester, monobloc construction Insulation resistance > 5000 MΩ Contact material Copper alloy, gold over nickel Contact type 0.6 diagonal solder pin, at 90° Contact resistance 5mΩ max. Current rating 3A per contact (in isolation) 1A per contact (through all contacts simultaneously) Working voltage 200 Vdc or ac peak Test voltage 125V (max. 5 sec) Temp. range -25°C to +125°C Suitable PCB thickness 1.6mm Mating cycles 250 operations Key Characteristics Capacitance Attenuation (MHz) MIL-STD 220 db min Pin to shell: 3 0 to 2 1nf +80% -20% at 1kHz 10 5 100 20 1000 40 Standards MIL-STD-220 Cinch Filtered 'D' Connectors Solder termination connection Designed to limit cable borne EMI via a 1000pF capacitor from each contact to ground Enhances rejection levels in VHF & UHF bands Bright tin finish on steel backshells shields against RFI/EM and the potted construction allows use in hazardous environments Gold plated turned pin contacts High quality machined contact Flammability rating: UL94V-0 Suitable for military, industrial or commercial applications and computer interfacing etc

Product Detail

Popular items

5810130045, Cinch

Modice Headers Interfaces with Cinch SHS, industry standard harness connectors Features and Benefits Available with or without ferrite filtering option Epoxy sealed terminals for optimised sealing characteristics Centre threaded mating bushing Note For Enclosures see typically stock no 664-7220 . For Harness Connectors see typically stock no 664-7254 . For Header release tools see stock no's 664-7282 (SE) and 664-7286 (LE) Modular Integrated Connector Enclosure Cinch's Modular Integrated Connector Enclosures offer high quality sealed packaging solutions for rugged electronic control module applications.,The ModICE product line consists of two distinct enclosure sizes and 6 header configurations allowing 18, 30, 48 and 60 I/O mating to Cinch's SHS harness connectors. Snap-in header simplifies module assembly Options include ferrite filtering and intergrated heat sink Resistant to most fluids used in industrial applications Enclosure and Headers manufactured from glass filled polymer Sealing rated at IP65, IP66, IP67 and IP69K

Product Detail

Popular items

RS000170000EL1K, Cinch

Cinch Filter D-sub Plug and Socket Connectors with Solder Bucket Terminals Filter D-Sub plug and socket connectors with solder bucket terminals and turned pin contacts with epoxy encapsulated tubular capacitors individually inserted into them for maxmum resistance to hazardous environments. The rear shell of these filter D connectors is made from electrolytic nickel and the front shell is made from steel with a bright tin finish, in addition, the filtered d-sub plug connectors have grounding indents on the front shell for EMI/RFI shielding. These filter D subminiature plug and socket connectors have a capacitance of 1000 pF and 3.05mm diameter mounting holes. Standards Meets relevant dimensional requirements of CECC-73301-802; MIL-C-24308; DIN-14652; BS-9523; F0013; BT-217; HE-501 Standards CECC-73301-802; MIL-C-24308; DIN-41652; BS-9523; F0013; BT-217; HE-501 Cinch Filtered 'D' Connectors Solder termination connection Designed to limit cable borne EMI via a 1000pF capacitor from each contact to ground Enhances rejection levels in VHF & UHF bands Bright tin finish on steel backshells shields against RFI/EM and the potted construction allows use in hazardous environments Gold plated turned pin contacts High quality machined contact Flammability rating: UL94V-0 Suitable for military, industrial or commercial applications and computer interfacing etc

Product Detail

Popular items

27-8110, Cinch

BNC Connector Adapters A range of BNC coaxial connector adapters from Cinch that are designed for use with applications such as test equipment and analogue/digital connectivity.

Product Detail

Popular items

142-0701-401, Cinch

SMA Cable Connectors Cinch Connectivity range of professional grade crimp or solder cable mount SMA connectors have a stainless steel body and gold plated contact pin. The SMA connectors are available in a variety of configurations to suit any application. Wide operating frequency range - See manufacturers data sheet for permissible GHz range Crimp or solder options available Impedance - 50 Ohm Operating temperature - 65°C to + 165°C

Product Detail
