American Wire Gauge:
24 AWG
Current Rating:
2 A
Conductor Resistance:
78 O/km
Oil Resistant:
Yes
Outer Diameter:
5.9mm
Standards Met:
cUL, cULus, EAC, IEC 61076-2-104, UL
Connector 1 Number of Contacts:
8
Voltage Rating:
30 V
Shielded/Unshielded:
Shielded
Maximum Operating Temperature:
+80°C
IP Rating:
IP65, IP67
Minimum Bend Radius:
5 x D (Fixed), 10 x D (Flexible)
Fire Behaviour:
Halogen Free
Connector 1 Gender:
Female
Length:
10m
Sheath Material:
Polyurethane PUR
Series:
SAC-8P-10.0-PUR/M12FR SH
Connector 1 Housing Gender:
Female
Coding:
A
Sheath Colour:
Black
Cross Sectional Area:
0.14 mm²
Minimum Operating Temperature:
-5 (Flexible) °C, -25 9Fixed) °C
Connector 2:
Unterminated
Connector 1:
M12
Insulation Material:
PP
1st Connector Orientation:
A
2nd Connector Mounting Type:
-
HTSUS:
8544.42.9090
RoHS Status:
RoHS Compliant
Cable Material:
Polyurethane (PUR)
Usage:
Industrial Environments
Shielding:
Shielded
1st Connector Number of Positions Loaded:
All
1st Connector Shell Size - Insert:
M12
2nd Connector Type:
Wire Leads
Assembly Configuration:
Standard
2nd Connector Number of Positions:
-
Package:
Bulk
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Length:
32.8' (10.00m)
1st Connector Gender:
Female Sockets
standardLeadTime:
4 Weeks
1st Connector Type:
Plug, Right Angle
2nd Connector Shell Size - Insert:
-
1st Connector Number of Positions:
8
Ingress Protection:
IP65/IP67 - Dust Tight, Water Resistant, Waterproof
Color:
Black
Series:
-
2nd Connector Orientation:
-
Cable Type:
Round
2nd Connector Number of Positions Loaded:
-
2nd Connector Gender:
-
1st Connector Mounting Type:
Free Hanging (In-Line)
ECCN:
EAR99
