American Wire Gauge:
22 AWG
Current Rating:
4 A
Standards Met:
cUL, cULus, EAC, UL
Mounting Type:
Panel Mount
IP Rating:
IP67
Conductor Material:
Tinned Copper
Voltage Rating:
250 V
Coding:
A
Connector 1 Gender:
Male
Operating Temperature Range:
-25 → +85 °C
Length:
500mm
Cross Sectional Area:
0.34 mm²
Minimum Operating Temperature:
-25°C
Connector 2:
Unterminated
Number of Cores:
4
Conductor Resistance:
= 57.6 mΩ/m
Connector 1:
M12
Maximum Operating Temperature:
+85°C
Connector 1 Number of Contacts:
4
1st Connector Orientation:
A
2nd Connector Mounting Type:
-
HTSUS:
8544.42.9090
RoHS Status:
ROHS3 Compliant
Cable Material:
Thermoplastic Elastomer (TPE)
Usage:
Industrial Environments
Shielding:
Unshielded
1st Connector Number of Positions Loaded:
All
1st Connector Shell Size - Insert:
M12
REACH Status:
REACH Affected
2nd Connector Type:
Wire Leads
Assembly Configuration:
Standard
2nd Connector Number of Positions:
-
Package:
Bulk
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Length:
1.64' (500.00mm)
1st Connector Gender:
Male Pins
standardLeadTime:
8 Weeks
1st Connector Type:
Receptacle
2nd Connector Shell Size - Insert:
-
1st Connector Number of Positions:
4
Ingress Protection:
IP67 - Dust Tight, Waterproof
Color:
Multiple
Series:
-
2nd Connector Orientation:
-
Cable Type:
Individual
2nd Connector Number of Positions Loaded:
-
2nd Connector Gender:
-
1st Connector Mounting Type:
Panel Mount
ECCN:
EAR99
