American Wire Gauge:
24 AWG
Current Rating:
2 A
Conductor Resistance:
79.7 O/km
Number of Cores:
8
Outer Diameter:
5.7mm
Standards Met:
cUL, EAC, IEC 61076-2-101, UL
Connector 1 Number of Contacts:
8
Voltage Rating:
30 V
Shielded/Unshielded:
Unshielded
Maximum Operating Temperature:
+80°C
IP Rating:
IP65, IP67, IP68
Connector 1 Orientation:
Straight
Minimum Bend Radius:
44/ 8 x D mm
Fire Behaviour:
Flame Retardant
Connector 1 Gender:
Male
Length:
5m
Sheath Material:
PVC
Conductor Material:
Tinned Copper
Series:
SAC-8P-MS/ 5.0-542 SCO BK
Connector 1 Housing Gender:
Male
Coding:
A
Sheath Colour:
Yellow
Cross Sectional Area:
0.25 mm²
Minimum Operating Temperature:
-5(Flexible) °C, -40(Fixed) °C
Connector 2:
Unterminated
Connector 1:
M12
Insulation Material:
PVC
1st Connector Orientation:
A
2nd Connector Mounting Type:
-
HTSUS:
8544.42.9090
RoHS Status:
ROHS3 Compliant
Cable Material:
Polyvinyl Chloride (PVC)
Usage:
Industrial Environments
Shielding:
Unshielded
1st Connector Number of Positions Loaded:
All
1st Connector Shell Size - Insert:
M12
REACH Status:
REACH Affected
2nd Connector Type:
Wire Leads
Assembly Configuration:
Standard
2nd Connector Number of Positions:
-
Package:
Bulk
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Length:
16.40' (5.00m)
1st Connector Gender:
Male Pins
standardLeadTime:
5 Weeks
1st Connector Type:
Receptacle
2nd Connector Shell Size - Insert:
-
1st Connector Number of Positions:
8
Ingress Protection:
IP65/IP67/IP68 - Dust Tight, Water Resistant, Waterproof
Color:
Yellow
Series:
-
2nd Connector Orientation:
-
Cable Type:
Round
2nd Connector Number of Positions Loaded:
-
2nd Connector Gender:
-
1st Connector Mounting Type:
Free Hanging (In-Line)
ECCN:
EAR99
