HTSUS:
8504.40.7001
RoHS Status:
RoHS Compliant
Power (Watts):
-
Moisture Sensitivity Level (MSL):
Not Applicable
Type:
Bench (AC to DC)
Current Regulation - Line:
0.1% + 1mA, 0.2% + 1mA (3rd Output)
Voltage Regulation - Line:
0.1% + 100mV, 0.2% + 100mV (3rd Output)
Current - Output:
250mA, 250mA, 1A
Accuracy - Voltmeter; Ammeter:
0.5% + 1 digit
Package:
Bulk
Size / Dimension:
12.677" L x 10.433" W x 2.756" H (322.00mm x 265.00mm x 70.00mm)
Number of Characters:
3
Current Regulation - Load:
0.2% + 1mA, 1% + 1mA (3rd Output)
Voltage Regulation - Load:
0.2% + 100mV, 1% + 100mV (3rd Output)
Display Type:
LED
Features:
Regulated, Series and Parallel Modes
Weight:
6 lbs (2.7 kg)
Series:
-
Voltage - Output:
1.3 ~ 20VDC, 1.3 ~ 20VDC, 5VDC
Voltage - Supply:
108 ~ 250VAC
Ripple:
10mV rms
Number of Outputs:
3
ECCN:
EAR99
