Fuji Electric 7MBR75VB-060-50, M712 3 Phase Bridge IGBT Module, 75 A max, 600 V, Through Hole

7MBR75VB-060-50 Fuji Electric , M712 3 Phase Bridge IGBT Module, 75 A max, 600 V, Through Hole
7MBR75VB-060-50 Fuji Electric , M712 3 Phase Bridge IGBT Module, 75 A max, 600 V, Through Hole
Fuji Electric

Product Information

Configuration:
3 Phase Bridge
Dimensions:
122 x 62 x 17mm
Mounting Type:
Through Hole
Maximum Power Dissipation:
300 W
Maximum Continuous Collector Current:
75 A
Maximum Collector Emitter Voltage:
600 V
Height:
17mm
Width:
62mm
Length:
122mm
Maximum Gate Emitter Voltage:
±20V
Package Type:
M712
Channel Type:
N
Maximum Operating Temperature:
+150 °C
Pin Count:
24
Transistor Configuration:
3 Phase
RoHs Compliant
Checking for live stock

This is M712 3 Phase Bridge IGBT Module 75 A max 600 V Through Hole manufactured by Fuji Electric. The manufacturer part number is 7MBR75VB-060-50. The product is available in 3 phase bridge configuration. The given dimensions of the product include 122 x 62 x 17mm. The product is available in through hole configuration. In addition, the height is 17mm. Furthermore, the product is 62mm wide. Its accurate length is 122mm. The product is available in [Cannel Type] channel. It has a maximum operating temperature of +150 °c.
