Maximum Low Level Output Current:
-35mA
Dimensions:
12.95 x 7.6 x 2.4mm
Mounting Type:
Surface Mount
Maximum Propagation Delay Time @ Maximum CL:
165ns
Minimum Operating Supply Voltage:
-0.5 V
Logic Function:
Transceiver
Automotive Standard:
AEC-Q100
Package Type:
SOIC
Propagation Delay Test Condition:
50pF
Maximum Operating Supply Voltage:
7 V
Pin Count:
20
Maximum High Level Output Current:
35mA
HTSUS:
8542.39.0001
RoHS Status:
ROHS3 Compliant
Operating Temperature:
-55°C ~ 125°C (TA)
Input Type:
-
Package / Case:
20-SOIC (0.295", 7.50mm Width)
Number of Bits per Element:
8
REACH Status:
REACH Unaffected
Output Type:
3-State
Package:
Tube
Moisture Sensitivity Level (MSL):
3 (168 Hours)
standardLeadTime:
29 Weeks
Mounting Type:
Surface Mount
Series:
74HC
Logic Type:
Transceiver, Non-Inverting
Supplier Device Package:
20-SOIC
Voltage - Supply:
2V ~ 6V
Current - Output High, Low:
7.8mA, 7.8mA
Number of Elements:
1
Base Product Number:
74HC245
ECCN:
EAR99
