Maximum Drain Source Voltage:
30 V
Typical Gate Charge @ Vgs:
22 nC @ 4.5 V, 5.9 nC @ 4.5 V
Mounting Type:
Surface Mount
Channel Mode:
Enhancement
Maximum Power Dissipation:
2.5 W
Series:
OptiMOS
Maximum Gate Source Voltage:
+20 V
Maximum Gate Threshold Voltage:
2V
Height:
1.1mm
Width:
6.1mm
Length:
5.1mm
Maximum Drain Source Resistance:
7 mΩ
Package Type:
TISON
Number of Elements per Chip:
2
Minimum Operating Temperature:
-55 °C
Maximum Continuous Drain Current:
40 A
Minimum Gate Threshold Voltage:
1.2V
Channel Type:
N
Maximum Operating Temperature:
+150 °C
Pin Count:
8
