Automotive Standard:
AEC-Q101
Maximum Drain Source Voltage:
200 (Channel 3) V, 40 (Channel 1) V, 40 (Channel 2) V
Typical Gate Charge @ Vgs:
14 nC @ 100 V (Channel 3), 23 nC @ 20 V (Channel 2), 30.2 nC @ 20 V (Channel 1)
Mounting Type:
Surface Mount
Channel Mode:
Enhancement
Maximum Power Dissipation:
48 W, 48 W, 60 W
Maximum Gate Source Voltage:
20 V
Channel Type:
NPN
Maximum Gate Threshold Voltage:
2.5 (Channel 1) V, 2.5 (Channel 2) V, 3.5 (Channel 3) V
Maximum Drain Source Resistance:
0.0135 (Channel 2) Ω, 0.048 (Channel 1) Ω, 0.06 (Channel 3) Ω
Package Type:
Triple Die
Number of Elements per Chip:
3
Minimum Operating Temperature:
-55 °C
Maximum Continuous Drain Current:
30 A, 30 A, 20 A
Minimum Gate Threshold Voltage:
1.5 (Channel 1) V, 1.5 (Channel 2) V, 2.5 (Channel 3) V
Maximum Operating Temperature:
+175 °C
Pin Count:
10
Transistor Configuration:
Common Drain
