Lapp 3 Core 1.5 mm² Coiled Cable, Black Neoprene Sheath 2m, 18 A 750 V, H07RN-F

  • Enrgtech Part No: ET13998603
  • |
  • Manufacturer Part No:

    38101332

  • |
  • Manufacturer: Lapp
38101332 Lapp 3 Core 1.5 mm² Coiled Cable, Black Neoprene Sheath 2m, 18 A 750 V, H07RN-F
38101332
38101332 Lapp 3 Core 1.5 mm² Coiled Cable, Black Neoprene Sheath 2m, 18 A 750 V, H07RN-F
Lapp

Product Information

American Wire Gauge:
15 AWG
Current Rating:
18 A
Conductor Resistance:
13.3 Ω/km
European Harmonised Code:
H07RN-F
Number of Cores:
3
Outer Diameter:
10.1mm
Number of Strands:
30
Standards Met:
CE
Cable Shape:
Coiled Multicore
Core Strands:
30/0.25 mm
Conductor Strand Type:
Solid
Maximum Operating Temperature:
+60°C
Voltage Rating:
750 V
Fire Behaviour:
Flame Retardant
Length:
2m
Sheath Material:
Neoprene
Conductor Material:
Bare Copper
Series:
UNITRONIC
Size of Strands:
0.25 mm
Cable Type:
Coiled
Sheath Colour:
Black
Cross Sectional Area:
1.5 mm²
Minimum Operating Temperature:
-25°C
Insulation Material:
Rubber
RoHs Compliant
Checking for live stock

This is 3 Core 1.5 mm² Coiled Cable Black Neoprene Sheath 2m 18 A 750 V H07RN-F manufactured by Lapp. The manufacturer part number is 38101332. The product has a current rating of 18 a. It has a maximum operating temperature of +60°c. Moreover, the product has a nominal 750 v voltage rating. Its accurate length is 2m. The conductor is made from bare copper material. The product unitronic, is a highly preferred choice for users. It is a typical coiled cable. Whereas, the minimum operating temperature of the product is -25°c. It has a robust rubber insulation material.

pdf icon
LAPP Cable to Gland Cross Reference(Technical Reference)
pdf icon
Cable Selection Guide(Technical Reference)
pdf icon
H07 RN-F(Technical Reference)
