Repetitive Peak Forward Blocking Voltage:
600V
Repetitive Peak Reverse Voltage:
600V
Peak On-State Voltage:
1.55V
Dimensions:
15.5 x 4.6 x 21.1mm
Mounting Type:
Through Hole
Surge Current Rating:
260A
Rated Average On-State Current:
25A
Height:
21.1mm
Width:
4.6mm
Length:
15.5mm
Repetitive Peak Off-State Current:
3mA
Package Type:
TOP3
Minimum Operating Temperature:
-40 °C
Maximum Holding Current:
75mA
Maximum Gate Trigger Current:
50mA
Maximum Operating Temperature:
+125 °C
Pin Count:
3
Maximum Gate Trigger Voltage:
1.3V
HTSUS:
8541.30.0080
RoHS Status:
ROHS3 Compliant
Voltage - Off State:
600 V
Voltage - Gate Trigger (Vgt) (Max):
1.3 V
Operating Temperature:
-40°C ~ 125°C (TJ)
Package / Case:
TOP-3 Insulated
Current - Hold (Ih) (Max):
75 mA
REACH Status:
REACH Unaffected
Current - On State (It (RMS)) (Max):
25 A
Configuration:
Single
Package:
Tube
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Current - Gate Trigger (Igt) (Max):
50 mA
standardLeadTime:
99 Weeks
Current - Non Rep. Surge 50, 60Hz (Itsm):
250A, 260A
Mounting Type:
Through Hole
Series:
Snubberless™
Supplier Device Package:
TOP3
Triac Type:
Alternistor - Snubberless
Base Product Number:
BTA26
ECCN:
EAR99
