Width:
144mm
Height:
79mm
Length:
144mm
Weight:
1kg
IP Rating:
IP66
Chart Type:
Videographic
Dimensions:
144 x 144 x 79mm
Power Source:
Mains
Model Number p:
SM501FCB
Number of Inputs:
1
Parameter Measured:
Current, Millivolt, Resistance, Temperature, Voltage
Recorder Input Type:
mA, mV, RTD, Thermocouple, V
Maximum Operating Voltage:
265V ac
Minimum Operating Voltage:
85V ac
Maximum Current Measurement:
50mA
Maximum Voltage Measurement:
+25V
Current Measurement Resolution:
0.01 %
Maximum Resistance Measurement:
500 ￫ 10000Ω
Voltage Measurement Resolution:
0.01%
Maximum Temperature Measurement:
+1100 °F, +1300 °C, +1650 °F, +1700 °C, +1800 °C, +2350 (N) °F, +300 °C, +3000 (R) °F, +3270 (B) °F, +550 °F, +600 °C, +900 °C
Best Current Measurement Accuracy:
±0.2 %
Best Voltage Measurement Accuracy:
±0.2 %
Resistance Measurement Resolution:
0.01%
Temperature Measurement Resolution:
0.01%
Best Resistance Measurement Accuracy:
±0.1 %
Best Temperature Measurement Accuracy:
±0.1 %
