Width:
295mm
Height:
97mm
Length:
250mm
Series:
TGF4000
Weight:
3.1kg
Calibrated:
RSCAL
Dimensions:
250 x 295 x 97mm
Model Number:
TGF4042
FM Modulation:
Yes
Interface Type:
GPIB, LAN, USB
Variable Sweep:
Yes
Input Impedance:
10 kΩ
Output Impedance:
50Ω
TTL Output Level:
10V Pk-Pk
Digital Frequency:
Yes
Time Base Accuracy:
<±1 (Initial Settling Error) ppm, <±1(Oscillator Aging Rate) ppm, <1(Temperature Range) ppm
Digital Amplitude and Offset:
Yes
Internal Linear and Log Sweep:
Yes
Maximum Operating Temperature:
+40°C
Minimum Operating Temperature:
+5°C
Maximum Frequency Range Sinewave:
40MHz
Minimum Frequency Range Sinewave:
1µHz
Maximum Frequency Range Triangle/Saw:
5MHz
Minimum Frequency Range Triangle/Saw:
1µHz
Internal and External Amplitude Modulation:
Yes
Frequency Range Square Pulse and Arbitrary Waveform:
1 μHz → 25 MHz (Square & Pulse), 40 (Arbitrary) MHz
Maximum Frequency Range Square Pulse and Arbitrary Waveform:
25 (Square & Pulse) MHz, 40 (Arbitrary) MHz
Minimum Frequency Range Square Pulse and Arbitrary Waveform:
1 μHz
