Width:
250mm
Height:
97mm
Length:
270mm
Series:
TGxA
Weight:
2.6kg
Dimensions:
270 x 250 x 97mm
Model Number:
TG2511A
FM Modulation:
Yes
Interface Type:
RS232
Variable Sweep:
Yes
Input Impedance:
10 kΩ
Output Amplitude:
20V Pk-Pk
Output Impedance:
50Ω
TTL Output Level:
3V
Digital Frequency:
Yes
Number of Channels:
1
Operating Temperature Range:
+5 → +40 °C
Digital Amplitude and Offset:
Yes
Internal Linear and Log Sweep:
Yes
Maximum Operating Temperature:
+40°C
Minimum Operating Temperature:
+5°C
Maximum Frequency Range Sinewave:
25MHz
Minimum Frequency Range Sinewave:
1µHz
Maximum Frequency Range Triangle/Saw:
1MHz
Minimum Frequency Range Triangle/Saw:
1µHz
Internal and External Amplitude Modulation:
Yes
Frequency Range Square Pulse and Arbitrary Waveform:
1 μHz → 10 MHz, 1 μHz → 50 MHz, 500 μHz → 12.5 MHz
Maximum Frequency Range Square Pulse and Arbitrary Waveform:
10 MHz, 12.5 MHz, 50 MHz
Minimum Frequency Range Square Pulse and Arbitrary Waveform:
1 μHz, 500 μHz
