Width:
90mm
Height:
45mm
Length:
182mm
Weight:
354g
True RMS:
No
Calibrated:
UKAS
Dimensions:
182 x 90 x 45mm
Battery Type:
9 V
Display Type:
Digital
Model Number p:
AM-520-EUR
Multimeter Type:
Handheld
Maximum Frequency:
400Hz
Functions Measured:
AC Current, AC Voltage, Capacitance, DC Current, DC Voltage, Resistance, Temperature
Safety Category Level:
CAT II, CAT III
Safety Category Voltage:
600 V, 1000V
Best AC Current Accuracy:
±1.2% + 2 Digits
Best AC Voltage Accuracy:
±1% + 3 Digits
Best DC Current Accuracy:
±1% + 2 Digits
Best DC Voltage Accuracy:
±0.8% + 1 Digits
Best Resistance Measurement Accuracy:
±1.2% + 2 Digits
Best Capacitance Measurement Accuracy:
±3% + 5 Digits
Best Temperature Measurement Accuracy:
±1% + 8 Digits
Absolute Maximum AC Current Measurement:
10A ac
Absolute Maximum AC Voltage Measurement:
750V ac
Absolute Maximum DC Current Measurement:
10A dc
Absolute Maximum DC Voltage Measurement:
1000V dc
Absolute Maximum Resistance Measurement:
40MΩ
Absolute Maximum Capacitance Measurement:
4mF
Absolute Maximum Temperature Measurement:
+1000°C
