Width:
387.4mm
Height:
107.2mm
Length:
224mm
Weight:
4.5kg
True RMS:
Yes
Calibrated:
RSCAL
Dimensions:
224 x 387.4 x 107.2mm
Battery Type:
Li-Ion
Display Type:
6.5 Digital
Model Number p:
DMM6500
Multimeter Type:
Touchscreen Bench
Maximum Frequency:
300kHz
Functions Measured:
AC Current, AC Voltage, Capacitance, Continuity, DC Current, DC Voltage, Diode, Frequency, Period, Resistance, Temperature
Safety Category Level:
CAT II
Safety Category Voltage:
1000V
Maximum Operating Temperature:
+50°C
Minimum Operating Temperature:
0°C
Resistance Measurement Resolution:
1µΩ
Capacitance Measurement Resolution:
0.1pF
Temperature Measurement Resolution:
0.001°C
Absolute Maximum AC Current Measurement:
10.1A ac
Absolute Maximum AC Voltage Measurement:
750V ac
Absolute Maximum DC Current Measurement:
10.1A dc
Absolute Maximum DC Voltage Measurement:
1010V dc
Absolute Maximum Resistance Measurement:
120MΩ
Absolute Maximum Capacitance Measurement:
120µF
Absolute Maximum Temperature Measurement:
+1000 °C, +1300 °C, +1372 °C, +1768 °C, +1820 °C, +400 °C, +760°C
